2024-01-09
Low-Cost High Gain Sea Pimp-Shaped Dual Band Monopole Antenna for Mobile 4G/5G/LTE41/WLAN Application
By
Progress In Electromagnetics Research C, Vol. 140, 41-51, 2024
Abstract
This research aimed to design a sea pimp-shaped monopole antenna by using etching and cutting techniques, combined with the addition of reflector, to modify the antenna structure to support the bandwidth standard according to GSM-850 (0.82-0.90 GHz), GSM-900 (0.88-0.96 GHz), DCS (1.72-1.88 GHz), PCS (1.85-1.99 GHz), UMTS (1.92-2.17 GHz), 5G Band40 (2.30-2.40 GHz), LTE41 (2.496-2.690 GHz), and WLAN IEEE 802.11b/g/n (2.4-2.48 GHz). This antenna used a galvanized metal sheet with a conductivity of 3.56 x 107 s/m to fabricate the structure of the radiator, ground plane, and reflector. The reflector modifies radiation patterns and increases the gain of the antenna. The antenna structure used the CST program for simulation to determine the optimal parameters and property values. As a result of replication, the antenna had a dual-band with a reflection coefficient S11 at 915 MHz (736-1040 MHz) of -26.70 dB and a frequency at 2.28 GHz (1.68-2.94 GHz) of -20.15 dB. The antenna gains are 6.70 and 8.47 dBi, an increase of 83.56% and 44.04% over the antenna without a reflector, respectively. The antenna had a unidirectional pattern in all the frequency ranges which can be utilized for the purpose of RF energy-harvesting (RF-EH) systems to provide power to low-power electronic systems.
Citation
Suwat Sakulchat, Amnoiy Ruengwaree, Watcharaphon Naktong, Pramuk Unahalekhaka, and Sommart Promput, "Low-Cost High Gain Sea Pimp-Shaped Dual Band Monopole Antenna for Mobile 4G/5G/LTE41/WLAN Application," Progress In Electromagnetics Research C, Vol. 140, 41-51, 2024.
doi:10.2528/PIERC23102607
References

1. Takamura, Hideo, Akihisa Nakajima, and Koji Yamamoto, "Network and signaling structure based on personal digital cellular telecommunication system concept," IEEE 43rd Vehicular Technology Conference, 922--926, 1993.

2. Wang, Jong C. and Bill Hsu, "On the analysis of a cellular mobile telecommunication electrical power system," 2004 IEEE International Conference on Electric Utility Deregulation, Restructuring and Power Technologies Proceedings, Vol. 2, 535--539, 2004.

3. Saeed, Rashid A., Amran Bin Hj Naemat, Azrin Bin Aris, and Mat Kamil Bin Awang, "Design and evaluation of lightweight IEEE 802.11 p-based TDMA MAC method for road side-to-vehicle communications," 2010 The 12th International Conference on Advanced Communication Technology (ICACT), Vol. 2, 1483--1488, 2010.

4. Tang, Xiang-Guo and Zhi Ding, "Low-complexity iterative equalization for EDGE with bidirectional processing," IEEE Transactions on Wireless Communications, Vol. 4, No. 5, 1963--1968, 2005.

5. Kim, Yong-Jin, Sung-Soo Nam, and Hong-Min Lee, "Frequency selective surface superstrate for wideband code division multiple access system," 2009 European Wireless Technology Conference, 33--36, 2009.

6. Ko, Haneul, Giwon Lee, Dongeun Suh, Sangheon Pack, and Xuemin Shen, "An optimized and distributed data packet forwarding scheme in LTE/LTE-A networks," IEEE Transactions on Vehicular Technology, Vol. 65, No. 5, 3462--3473, 2015.

7. de Andrade, Tiago P. C., Carlos A Astudillo, and Nelson LS da Fonseca, "Allocation of control resources for machine-to-machine and human-to-human communications over LTE/LTE-A networks," IEEE Internet of Things Journal, Vol. 3, No. 3, 366--377, 2016.

8. Cao, Jin, Maode Ma, Hui Li, Yueyu Zhang, and Zhenxing Luo, "A survey on security aspects for LTE and LTE-A networks," IEEE Communications Surveys & Tutorials, Vol. 16, No. 1, 283--302, 2013.

9. Awwad, Mohammad, Noor Rafaiah, and Omar A Saraereh, "Design of mimo antenna array for 5G smart phone applications operating in LTE bands," 2019 8th Asia-Pacific Conference on Antennas and Propagation (APCAP), 1--2, 2019.

10. Karli, Radouane and Hassan Ammor, "A simple and original design of multi-band microstrip patch antenna for wireless communication," International Journal of Microwaves Applications, Vol. 2, No. 4, 1303-1306, 2013.

11. Malek, M. A., S. Hakimi, S. K. Abdul Rahim, and A. K. Evizal, "Dual-band CPW-fed transparent antenna for active RFID tags," IEEE Antennas and Wireless Propagation Letters, Vol. 14, 919--922, 2014.

12. Li, Li, Xiaoliang Zhang, Xiaoli Yin, and Le Zhou, "A compact triple-band printed monopole antenna for WLAN/WiMAX applications," IEEE Antennas and Wireless Propagation Letters, Vol. 15, 1853--1855, 2016.

13. Chanramrd, S., W. Naktong, P Thongbor, S. Sakulchat, A. Ruengwaree, and A. Namsang, "The structure tuning of plugs-shaped monopole antenna for wireless communication applications," 2017 International Symposium on Antennas and Propagation (ISAP), 1--2, 2017.

14. Kim, Woo-Su and Joong-Han Yoon, "A design for a CPW-fed monopole antenna with two modified half circular rings for WLAN/WiMAX operations," Journal of Information and Communication Convergence Engineering, Vol. 13, No. 3, 159--166, 2015.
doi:10.6109/jicce.2015.13.3.159

15. Kornsing, S., A. Innok, W. Naktong, and A. Ruengwaree, "The ring antenna with circular probe feeding for MIMO systems," 2017 International Symposium on Antennas and Propagation (ISAP), 1--2, 2017.

16. Liang, Jianxin, Choo C. Chiau, Xiaodong Chen, and Clive G. Parini, "Study of a printed circular disc monopole antenna for UWB systems," IEEE Transactions on Antennas and Propagation, Vol. 53, No. 11, 3500--3504, 2005.

17. Qiu, Jinghui and Jiaran Qi, "Study on the properties of circular monopole antenna," 2006 6th International Conference on ITS Telecommunications, 422--425, 2006.

18. Powell, Johnna and Anantha Chandrakasan, "Spiral slot patch antenna and circular disc monopole antenna for 3.1--10.6 GHz ultra wideband communication," ISAP 2004, Vol. 8, 1--10, 2004.

19. Zhong, L. L., J. H. Qiu, N. Zhang, and B. Zhao, "Novel ultrawide-band wide beam circular polarization antenna," Asia Pacific Microwave Conference (APMC), 1--4, 2007.

20. Khoomwong, Ekajit and Chuwong Phongcharoenpanich, "Characteristics of a dual-broadband antenna with crossed elliptical probes and L-shaped slits," 2017 International Symposium on Antennas and Propagation (ISAP), 1--2, 2017.

21. Mardikar, Amrita, Ravi Mohan, Mahima Arrawatia, and Girish Kumar, "Dual band dual circular ring monopole antenna," 2015 Twenty First National Conference on Communications (NCC), 1--5, 2015.

22. Kumar, Nilesh, Krishan Kumar Singh, and Ritesh K. Badhai, "A tapered feed circular monopole super ultra-wideband (UWB) printed antenna," 2016 International Conference on Communication and Signal Processing (ICCSP), 1943--1946, 2016.

23. Ruengwaree, Amnoiy, Watcharaphon Naktong, and Apirada Namsang, "A TE-shaped monopole antenna with semicircle etching technique on ground plane for UWB applications," 2013 Proceedings of The International Symposium on Antennas & Propagation, Vol. 1, 95--98, 2013.

24. Naktong, W., A. Ruengwaree, and P. Tajchai, "A study of tuning the CPW fed basic geometric monopole antenna for UWB applications," Naresuan University Engineering Journal, Vol. 15, 17-32, 2020.

25. Dash, Sounik Kiran Kumar and Taimoor Khan, "Reflector backed conical dielectric resonator antenna with enhanced gain," 2018 IEEE Indian Conference on Antennas and Propogation (InCAP), 1--3, 2018.

26. Ranga, Yogesh, Ladislau Matekovits, Karu P Esselle, and Andrew R Weily, "Enhanced gain UWB slot antenna with multilayer frequency-selective surface reflector," 2011 International Workshop on Antenna Technology (iWAT), 176--179, 2011.

27. Prakash, Pooja, Mahesh P Abegaonkar, A Basu, and Shiban K Koul, "Gain enhancement of a CPW-fed monopole antenna using polarization-insensitive AMC structure," IEEE Antennas and Wireless Propagation Letters, Vol. 12, 1315--1318, 2013.

28. Naktong, W., B. Piyadanai, T. Patsakul, and A. Ruengwaree, "A Study of the placement of the ring antenna with circular-shaped probe feeding for MIMO system application," EENET Journal, Vol. 1, No. 2, 1-4, 2017.

29. Agrawall, Narayan P., Girish Kumar, and K. P. Ray, "Wide-band planar monopole antennas," IEEE Transactions on Antennas and Propagation, Vol. 46, No. 2, 294--295, 1998.
