Abstract

A compact selective ultra-wideband bandpass filter primarily based on a multi-mode resonator is presented in this paper. A modified elliptical split-ring resonator (SRR) embedded in a variant of the ring resonator is employed to configure a microstrip ultra-wideband (UWB) triple-notched bandpass filter with improved in-band and out-of-band filter properties. Further, the bent inter-digital coupled lines with aperture at the backside are applied to overall filter size miniaturization apart from contributing tight coupling through the entire structure. The three notches facilitated by the modified elliptic SRR have gained the ability to suppress the wireless local area network (WLAN) (5.48 GHz), C band RADAR (7.68 GHz), X band RADAR (8.82 GHz) interfering signals profoundly within the UWB. Simultaneously, the other filter attributes likely a uniform forward transmission coefficient with minimum attenuation (0.46 dB~1.52 dB), a high skirt factor (0.88), a wide passband (6.52 GHz) with high fractional bandwidth (FBW) (103.16%), broad upper stopband (3.47 GHz), etc. together establish the proposed filter, suitable for practical UWB applications. The uniqueness of this design lies in the flexibility to configure the filter as either a double-notched or a triple-notched bandpass filter by altering only the aspect ratios of elliptical SRR. Simulated filter characteristics are compared with the results obtained by measuring the fabricated prototype, and a good accordance between the compared outcomes validates the design pertinence well.

1. Federal Communications Commission, , Revision of Part 15 of the commission's rules regarding ultra-wideband transmission systems, First Report and Order, FCC 02, V48, Apr. 2002.

2. Hao, Z. and J. Hong, "Ultra wideband filter technologies," IEEE Microwave Magazine, Vol. 11, No. 4, 56-68, 2010.
doi:10.1109/MMM.2010.936494

3. Singhal, P. K., S. Mathur, and R. N. Baral, "Ultra-wide microstrip bandpass filter using short circuited stubs," J. Electr. Electron. Eng. Res., Vol. 3, No. 6, 101-107, Aug. 2011.

4. Modak, S., P. P. Shome, Md. A. Halimi, T. Khan, A. A. Kishk, and T. A. Denidni, "Band-stop filtering for electromagnetic interference rejection in printed UWB components using single compact archimedean spiral EBG cell," Progress In Electromagnetics Research C, Vol. 126, 23-37, 2022.
doi:10.2528/PIERC22082407

5. Zheng, X. and T. Jiang, "Triple notches bandstop microstrip filter based on archimedean spiral electromagnetic bandgap structure," Electronics, Vol. 8, No. 9, 964, 1-15, Aug. 2019.

6. Sazid, M. and N. S. Raghava, "Planar UWB-bandpass filter with multiple passband transmission zeros," AEU-International Journal of Electronics and Communications, Vol. 134, 1-7, Mar. 2021.

7. Siddiqui, J. Y., C. Saha, and Y. M. M. Antar, "Compact dual-SRR-loaded UWB monopole antenna with dual frequency and wideband notch characteristics," IEEE Antennas Wireless Propag. Lett., Vol. 14, 100-103, 2015.
doi:10.1109/LAWP.2014.2356135

8. El Omari El Bakali, H., H. Elftouh, A. Farkhsi, A. Zakriti, and M. El Ouahabi, "Design of a super compact UWB filter based on hybrid technique with a notch band using open circuited stubs," Advanced Electromagnetics, Vol. 9, No. 3, 39-46, Dec. 2020.
doi:10.7716/aem.v9i3.1521

9. Fahmy, W. M., A. E. Farahat, K. F. A. Hussein, and A.-E.-H. A. Ammar, "High Q-factor bandstop filter based on CPW resonator broadside-coupled to CPW through-line," Progress In Electromagnetics Research B, Vol. 86, 121-138, 2020.
doi:10.2528/PIERB19122305

10. Taibi, A., M. Trabelsi, A. A. Saadi, and , "Efficient design approach of triple notched UWB filter," AEU-International Journal of Electronics and Communications, Vol. 131, 1-7, Mar. 2021.

11. Basit, A., M. I. Khattak, and M. Alhassan, "Design and analysis of a microstrip planar UWB bandpass filter with triple notch bands for WiMAX, WLAN, and X-band satellite communication systems," Progress In Electromagnetics Research M, Vol. 93, 155-164, 2020.
doi:10.2528/PIERM20042602

12. Chakraborty, P., P. P. Shome, J. R. Panda, and A. Deb, "Highly selective UWB bandpass filter with multi-notch characteristics using comb shaped resonator," Progress In Electromagnetics Research M, Vol. 108, 89-101, 2022.
doi:10.2528/PIERM21112601

13. Wang, C., X. Xi, Y. Zhao, and X. Shi, "Compact tri-notched wideband bandpass filter based on multiple resonances with wide upper stopband," Microw. Opt. Technol. Lett., Vol. 62, No. 12, 3842-3847, Aug. 2020.
doi:10.1002/mop.32540

14. Gao, Z., P. Wu, Y. Zhang, "A new compact microstrip ultra-wideband (UWB) bandstop filter with good performance," Progress In Electromagnetics Research Letters, Vol. 93, 9-12, 2020.
doi:10.2528/PIERL20052304

15. Dardeer, O. M., H. A. Elsadek, H. M. Elhennawy, and E. A. Abdallah, "Ultra-wideband bandstop filter with multi transmission zeros using in-line coupled lines for 4G/5G mobile applications," AEU-International Journal of Electronics and Communications, Vol. 131, 1-6, 2021.

16. Xu, Z., "UWB bandpass SSL filter with an adjustable notched band and four transmission zeros," Electron. Lett., Vol. 57, No. 24, 930-932, Nov. 2021.
doi:10.1049/ell2.12306

17. Yadav, D., M. P. Abegaonkar, S. K. Koul, V. Tiwari, and D. Bhatnagar, "A compact dual band-notched UWB circular monopole antenna with parasitic resonators," AEU-International Journal of Electronics and Communications, Vol. 84, 313-320, 2018.

18. Li, J., C. Ding, F. Wei, and X. W. Shi, "Compact UWB BPF with notch band based on SW-HMSIW," Electron. Lett., Vol. 51, No. 17, 1338-1339, Aug. 2015.
doi:10.1049/el.2015.0449

19. Ansoft Corporation, , , Ansoft HFSS (Version 13).

20. Zhu, L., S. Sun, and R. Li, Microwave Bandpass Filters for Wideband Communications, Ch. 2, John Wiley & Sons, Inc., Hoboken, NJ, 2012.
doi:10.1002/9781118197981

21. Kumari, P., P. Sarkar, and R. Ghatak, "A multi-stub loaded compact UWB BPF with a broad notch band and extended stopband characteristics," Int. J. RF Microw. Comput.-Aided Eng., Vol. 30, No. 4, 1-8, Jan. 2020.
doi:10.1002/mmce.22138

22. Weng, M. H., F. Z. Zheng, H. Z. Lai, and S. K. Liu, "Compact ultra-wideband bandpass filters achieved by using a stub-loaded stepped impedance," Electronics, Vol. 9, No. 2, 1-12, Jan. 2020.
doi:10.3390/electronics9020209

Dr. Piali Chakraborty

Dr. Jyoti Ranjan Panda

Dr. Arindam Deb

Dr. Sudhakar Sahu

Professor Jibendu Roy
