Planar Monopole UWB Antenna for USB Dongle Application

Rekha P. Labade,

Dr. Rekha P. Labade

Symbiosis International University

India

Homepage

Avinash Tambe,

Mr. Avinash Tambe

Electronics and Telecommunication Engineering

Amrutvahini College Of Engineering

India

Homepage

Shankar Deosarkar,

Dr. Shankar Deosarkar

Babasaheb Ambedkar Technological University

India

Homepage

Narayan Pisharoty

Dr. Narayan Pisharoty

Dr Babasaheb Ambedkar Technological Institute

India

Homepage

Progress In Electromagnetics Research C, Vol. 60, 37-46, 2015

doi:10.2528/PIERC15092303

Abstract

In this communication, a systematic approach for design of planar monopole ultra-wideband (UWB; 3.1~10.6 GHz) antenna for wireless USB dongle has been proposed. The simple planar monopole antenna consists of a rectangular metallic radiating patch whose modal analysis is carried out first by means of the Theory of Characteristic Modes (TCM), in order to identify the different radiating modes and get the physical insights of these radiating modes of the antenna. Further, based on the physical evidences obtained from the radiating modes of the similar planar monopole antenna, a bevel transition feed with rectangular slot has been used to enhance the bandwidth and obtain the desired radiation characteristics of the proposed antenna. The modal analysis is carried out using characteristic modes (CM) analysis tool in CADFEKO 7.0 simulation software. The proposed antenna exhibits a very compact dimensions of 12 mm × 16 mm × 5 mm and yields a good insights in simulated and measured impedance bandwidth of 3.1~12 GHz with VSWR < 2. Furthermore, the proposed antenna exhibits symmetrical radiation patterns, stable-high gain and efficiency and ultra-wide bandwidth making it suitable candidate for practical UWB-USB applications.

Citation

Copy Export

Rekha P. Labade, Avinash Tambe, Shankar Deosarkar, and Narayan Pisharoty, "Planar Monopole UWB Antenna for USB Dongle Application," Progress In Electromagnetics Research C, Vol. 60, 37-46, 2015.
doi:10.2528/PIERC15092303

References

1. Labade, R., S. Deosarkar, and N. Pishoroty, "A novel integrated bluetooth dual band UWB antenna for wireless communication," International Journal of Microwave and Optical Technology, Vol. 10, No. 3, 195-201, 2015.

2. Labade, R., S. B. Deosarkar, and N. Pishoroty, "Design and implementation of an integrated bluetooth ultrawideband monopole antenna," Australian Journal of Basic and Applied Sciences, Vol. 15, No. 8, 60-66, 2014.

3. Federal Communications Commission "Revision of Part 15 of the commissions rules regarding ultrawideband transmission systems,", First Note and Order, ET-Docket 98-153, Washington, DC, 2002.

4. Fabrs, M. C., "Systematic design of antennas using the theory of characteristic modes,", Ph.D. Dissertation, Feb. 2007.

5. Chu, L. J., "Physical limitations of omni-directional antenna," Journal of Applied Physics, Vol. 19, 1163-1175, Dec. 1948.
doi:10.1063/1.1715038

6. Harrington, R. F. and J. R. Mautz, "Computation of characteristic modes for conducting bodies," IEEE Transactions on Antennas and Propagation, Vol. 19, No. 5, 629-639, Sep. 1971.
doi:10.1109/TAP.1971.1139990

7. Su, S.-W.(Stephen), J.-H. Chou, and K.-L. Wong, "Internal ultrawideband monopole antenna for wireless USB dongle applications," IEEE Transactions on Antennas and Propagation, Vol. 55, No. 4, Apr. 2007.

8. Lee, J., S. Hong, J. Shin, and J. Choi, "Compact ultra wideband monopole antenna for wireless communication application," IEEE Transactions on Antennas and Propagation, Vol. 57, No. 9, Sep. 2009.

9. Tu, S., Y.-C. Jiao, Z. Zhang, Y. Song, and S.-M. Ning, "Small internal 2.4-GHz/UWB antenna for wireless dongle applications," IEEE Antennas and Wireless Propagation Letters, Vol. 9, 2010.

10. Gong, J.-G., Y.-C. Jiao, Q. Li, Y. Song, and J. Wang, "Compact internal wideband antenna for wireless USB dongle application," IEEE Antennas and Wireless Propagation Letters, Vol. 9, 2010.

11. Garbacz, R. J., "A generalized expansion for radiated and scattered fields,", Ph.D. Dissertation, Ohio State University, Columbus, 1968.

12. Harrington, R. F. and J. R. Mautz, "Theory of characteristic modes for conducting bodies," IEEE Transaction on Antennas and Propagation, Vol. 19, 348-358, 1971.

13. Tambe, A. and R. P. Labade, "A novel design approach for multimode multiband MIMO antenna using modal analysis," The 11th India IEEE Conference, INDICON, 1-5, 2014.

14. Valderas, D., J. I. Sancho, D. Puente, et al. Ultrawideband Antennas, Design and Application, Imperial College Press, 2011.
