PIER Letters | PIER Journals

2009-09-23

PIER Letters

Vol. 11, 173-181, 2009

doi:10.2528/PIERL09082004

download: 304

Measure the Complex Permeability of Ferromagnetic Thin Films: Comparison Shorted Microstrip Method with Microstrip Transmission Method

Yunqiu Wu , Zong-Xi Tang , Yuehang Xu and Biao Zhang

In this paper, two broadband measurement methods, shorted microstrip method and microstrip trnasmission method, are discussed, and the complex permeability of ferromagnetic thin films is measured from 100MHz to 18GHz. The S-parameters of the two measurement fixtures are measured by vector network analyzer (VNA). The perturbations of the thin film loaded in the measurement fixture are analyzed; the discontinuity between coaxial and microstrip is considered; the effective permeability is deduced from measured S-parameters; the permeability of ferromagnetic thin films is extracted from effective permeability by using conformal mapping. The results show that the experimental results agree with the theoretical ones closely, and higher measurement sensitivity and accuracy are achieved by using shorted microstrip method.

MEASURE THE COMPLEX PERMEABILITY OF FERROMAGNETIC THIN FILMS: COMPARISON SHORTED MICROSTRIP METHOD WITH MICROSTRIP TRANSMISSION METHOD

2009-09-23

PIER Letters

Vol. 11, 167-172, 2009

doi:10.2528/PIERL09082407

download: 324

A Compact Microstrip Bandstop Filter

Saeed Fallahzadeh and Majid Tayarani

In this paper, a novel microstrip bandstop filter by etching a square split ring in the center of microstrip line is proposed. Low insertion loss in the passband, high rejection level and integrated structure should be mentioned as advantages for this resonator. A transmission line model for this resonator is introduced and its resonant frequency is calculated analytically. Good agreement between the experimental results, full-wave simulation, transmission line model and analytical result has been achieved.

2009-09-21

PIER Letters

Vol. 11, 159-165, 2009

doi:10.2528/PIERL09080206

download: 227

Influence of Disorder on a Chirped Mirror Based on Porous Silicon

Jesus Manzanares-Martinez , Paola Castro-Garay and Efrain Urrutia-Banuelos

We report on the modeling of light reflection in disordered chirped mirrors with a photonic band gap in the visible. The stop band limits have a threshold-like behavior as a function of disorder and sustain a certain amount of disorder before changing. We determine the disorder value that leads to a substantial broadening of the total reflection range.

INFLUENCE OF DISORDER ON A CHIRPED MIRROR BASED ON POROUS SILICON

2009-09-21

PIER Letters

Vol. 11, 149-158, 2009

doi:10.2528/PIERL09082406

download: 232

Controlling the Frequency of Simultaneous Switching Noise Suppression by Using Embedded Dielectric Resonators in High-Impedance Surface Structure

Chin-Sheng Chang , Jian-Yi Li , Wen-Jeng Lin , Mau-Phon Houng , Lih-Shan Chen and Ding-Bing Lin

This work presents a novel design for high-impedance surface (HIS) embedded dielectric resonator (DR) structures to efficiently control bandwidth of suppressing simultaneous switching noise (SSN) in high speed digital printed circuit boards (PCBs). The proposed structure is designed by periodically embedding high dielectric constant materials into the substrate between a continuous power plane and a middle patch. A conventional HIS structure has only one resonance frequency to produce stopband while the proposed structure has two resonances to widen the suppression bandwidth. The -30 dB stopband of the proposed structure is about two times wider than that of a conventional HIS structure. The excellent SSN suppression behavior was verified by measurements and simulations.

CONTROLLING THE FREQUENCY OF SIMULTANEOUS SWITCHING NOISE SUPPRESSION BY USING EMBEDDED DIELECTRIC RESONATORS IN HIGH-IMPEDANCE SURFACE STRUCTURE

2009-09-20

PIER Letters

Vol. 11, 139-148, 2009

doi:10.2528/PIERL09082403

download: 253

Bazro₃:Yb Nanophosphor for Efficient Up-Conversion Light Emission

Luis-Armando Diaz-Torres , Elder De-la-Rosa , Jorge Oliva , Pedro Salas and Victor M. Castano

Strong visible green upconversion emission in nanocrystalline BaZrO₃:Yb³⁺ powder, obtained by a hydrothermal process at 100ºC, is reported. The unconverted emission has a quadratic dependence on the pump intensity with a lifetime around half that of the NIR lifetime. Results suggest cooperative upconversion as the mechanism responsible for the green fluorescence. This efficient Yb³⁺-based cooperative up-conversion process allows the development of novel emitting materials in the UV-VIS range.

BaZrO<sub>3</sub>:YB NANOPHOSPHOR FOR EFFICIENT UP-CONVERSION LIGHT EMISSION

2009-09-20

PIER Letters

Vol. 11, 129-137, 2009

doi:10.2528/PIERL09080101

download: 278

Enhanced Temperature Sensing by Using One-Dimensional Ternary Photonic Band Gap Structures

Anirudh Banerjee

This paper demonstrates a novel way to enhance the temperature sensitivity in one-dimensional (1D) photonic band gap (PBG) material by using a ternary periodic structure (i.e. three material layers constituting a period of lattice). The temperature sensitive wavelength band shift of (Si/SiO₂) periodic structure was significantly enhanced when the structure was modified by sandwiching a thin layer of Bi₄Ge₃O₁₂ between every two layers, constituting a period of lattice. When the thickness of sandwiched layer was increased further enhancement in temperature sensitivity was observed. These 1D ternary PBG structures can be substituted in place of 1D binary PBG for enhancing the temperature sensing performance.

ENHANCED TEMPERATURE SENSING BY USING ONE-DIMENSIONAL TERNARY PHOTONIC BAND GAP STRUCTURES

2009-09-20

PIER Letters

Vol. 11, 119-128, 2009

doi:10.2528/PIERL09071605

download: 303

Multi-Harmonic DC-Bias Network Based on Arbitrarily Width Modulated Microstrip Line

Samuel Ver-Hoeye , Carlos Vazquez-Antuna , Marta Gonzalez Corredoiras , Miguel Fernandez-Garcia , Luis Herran Ontanon and Fernando Las Heras Andres

In this work, we present a novel DC-bias network for multiharmonic microwave circuits based on an arbitrarily width-modulated microstrip line. The arbitrary shape of the width-modulated microstrip line is obtained by using multiple microstrip taper sections. The method is illustrated through the design of four different DC-bias networks blocking from 1 to 4 harmonic components of a 2.5 GHz signal. The designs with an optimum shape for the arbitrarily widthmodulated microstrip line have been manufactured and measured, obtaining a good agreement between the simulated and measured behavior.

MULTI-HARMONIC DC-BIAS NETWORK BASED ON ARBITRARILY WIDTH MODULATED MICROSTRIP LINE

2009-09-18

PIER Letters

Vol. 11, 113-118, 2009

doi:10.2528/PIERL09080801

download: 338

Compact Circularly Polarized Microstrip Antenna with Wide Beamwidth for Compass Satellite Service

Jing-Ya Deng , Ying-Zeng Yin , You-Huo Huang , Jie Ma and Qi-Zhong Liu

A compact circularly polarized (CP) microstrip antenna with inserted nine cross slots is proposed to reduce the size and widen the beamwidth. The antenna is operated at 1.268 GHz, and built by using a substrate with a coaxial probe feed. The impedance bandwidth (VSWR < 2) is 1.5% and the 3 dB axial ratio bandwidth is 0.52%. The measure gain is 4.5 dBi and beamwidth is about 110^o. The measured results for the compact CP antenna with embedded cross slots size shows that the resonate frequency is significantly lowered from 1.951 GHz to 1.268 GHz, corresponding to a 35% antenna size reduction compared with the one without any slot.

COMPACT CIRCULARLY POLARIZED MICROSTRIP ANTENNA WITH WIDE BEAMWIDTH FOR COMPASS SATELLITE SERVICE

2009-09-11

PIER Letters

Vol. 11, 103-112, 2009

doi:10.2528/PIERL09073001

download: 268

Rotational Stability of a Charged Dielectric Rigid Body in a Uniform Magnetic Field

Guo-Quan Zhou

Based on a new concept, i.e., charge moment tensor and the rotational equation of a charged dielectric rigid body about a fixed-point under a uniform external magnetic field, one symmetrical case has been rigorously solved. The rotational stability has been analyzed in detail for two cases, general and symmetrical, respectively, by means of some techniques of matrix analysis.

2009-09-11

PIER Letters

Vol. 11, 93-102, 2009

doi:10.2528/PIERL09071509

download: 432

Computational Modeling of Induction Heating Process

Mohammad Hossein Tavakoli , Hossein Karbaschi and Feridoun Samavat

An accurate 2D steady state mathematical model for induction heating process is described and additional results of electromagnetic field, eddy currents distribution and volumetric heat generation have been computed for a sample setup using a finite element method. For the calculations, the input voltage of induction coil is set to be 200 ν with a frequency of 10 kHz. It was shown that for the case considered here, the distribution of eddy currents density along the radius/thickness of the workpiece has a damped sinusoidal wave-shaped form.

COMPUTATIONAL MODELING OF INDUCTION HEATING PROCESS

2009-09-11

PIER Letters

Vol. 11, 83-91, 2009

doi:10.2528/PIERL09071809

download: 242

Compact CPW-Fed UWB Antenna with Dual Band-Notched Characteristics

Zhi-An Zheng and Qing-Xin Chu

In this paper, a coplanar waveguide fed (CPW-Fed) ultra-wideband (UWB) antenna with dual band-notched characteristics is proposed. Two symmetrical slots are etched from the ground plane to achieve the notched band at 5.5 GHz. The other notched band at 3.5 GHz is obtained by etching a split ring slot in the radiator. The simulation and measurement show that the proposed antenna achieves an impedance bandwidth of 3.1-10.6 GHz with VSWR < 2, except in the bands of 3.2-3.8 GHz and 4.8-6.2 GHz. A nearly omnidirectional radiation pattern and stable gain with variation less than 3 dB are also observed except in the two notched bands. Moreover, time-domain characteristics of the antenna are analyzed and discussed as well.

COMPACT CPW-FED UWB ANTENNA WITH DUAL BAND-NOTCHED CHARACTERISTICS

2009-09-11

PIER Letters

Vol. 11, 73-82, 2009

doi:10.2528/PIERL09071311

download: 255

Direct Modulation with Side-Mode Injection in Optical CATV Transport Systems

Wen-Jeng Ho , Hai-Han Lu , Ching-Hung Chang , Wen-Yi Lin and Heng-Sheng Su

A split-band directly modulated fiber optical CATV system employing -1 side-mode injection-locked and semiconductor optical amplifier (SOA)-based optical single sideband (SSB) modulation techniques is proposed and experimentally demonstrated. For our proposed systems, it is relatively simple to implement as only one SOA is required. Excellent performances of carrier-to-noise ratio (CNR), composite second order (CSO), and composite triple beat (CTB) were achieved over a-100 km single-mode fiber (SMF) transmission.

DIRECT MODULATION WITH SIDE-MODE INJECTION IN OPTICAL CATV TRANSPORT SYSTEMS

2009-09-04

PIER Letters

Vol. 11, 65-72, 2009

doi:10.2528/PIERL09080601

download: 232

Quasi-Lumped Design of UWB BPF Using Suspended Stripline

Xian-Jie Liao , Min-Hua Ho , Wei-Hong Hsu , Wei-Qin Xu and Li-Jing Lin

We propose a novel UWB bandpass filter (BPF) design using the suspended stripline (SSL). The filter composes of a lowpass and a high-pass circuit, both implemented by SSL structures. A notch response structure might be implemented to the filter by embedding a resonant slotline. The quasi-lumped elements circuit models were developed to analyze these circuits' performance. Experiments were conducted, and good agreements were observed between the measurements and simulations.

QUASI-LUMPED DESIGN OF UWB BPF USING SUSPENDED STRIPLINE

2009-09-02

PIER Letters

Vol. 11, 55-64, 2009

doi:10.2528/PIERL09070705

download: 539

Pattern Synthesis for Planar Array Based on Elements Rotation

Fan Zhang , Fu-Shun Zhang , Chen Lin , Gang Zhao and Yong-Chang Jiao

Aimed at improving the radiating characteristics (pattern and polarization) and simplifying the design of feeding network, a new approach is applied and discussed. For uniformly excited planar antenna array, by rotating each element in its local coordinates and determining the rotation angles of the elements, the 3D radiating characteristic of the planar antenna array can be improved. The Differential Evolution (DE) algorithm is applied for optimizing rotation angles of the elements. Furthermore, the effects of the elements rotation are discussed in detail.

PATTERN SYNTHESIS FOR PLANAR ARRAY BASED ON ELEMENTS ROTATION

2009-08-31

PIER Letters

Vol. 11, 47-54, 2009

doi:10.2528/PIERL09080207

download: 209

A Wideband and Dual Frequency Three-Dimensional Transition-Fed Circular Patch Antenna for Indoor Base Station Application

You-Huo Huang , Qi-Zhong Liu and Shi-Gang Zhou

The design and performance of a stacked patch antenna for wideband and dual-frequency operation are presented in this paper. The proposed antenna consists of a three dimensional (3D) circular transition-fed patch that is excited by a coaxial probe. By introducing a regular patch and a ring patch above the 3D circular transition-fed patch, good input impedance matching has been achieved over two frequency bands. The lower band possesses an impedance bandwidth (VSWR < 2) of 22.8% (0.775 to 0.975 GHz) and a peak gain of 5.2 dBi, while the upper band has an impedance bandwidth (VSWR < 2) of 65.8% (1.425 to 2.825 GHz) and a peak gain of 7.4 dBi. Other than the wideband and dual-band operation features, this antenna also has a beam tilted downward with a broadside beam pattern on the horizontal plane. Therefore, this antenna is very suitable for the indoor base station that is required to service several wireless communication systems, included CDMA800, GSM900, 3G, PCS, UMTS, BLUETOOTH and WLAN, by a single antenna.

A WIDEBAND AND DUAL FREQUENCY THREE-DIMENSIONAL TRANSITION-FED CIRCULAR PATCH ANTENNA FOR INDOOR BASE STATION APPLICATION

2009-08-31

PIER Letters

Vol. 11, 39-46, 2009

doi:10.2528/PIERL09080901

download: 244

Leaky Wave Antenna Realization by Composite Right/Left-Handed Transmission Line

Aya Fekry Abdelaziz , Tamer Mostafa Abuelfadl and Osman Lotfy Elsayed

This paper presents a realization of composite right/left handed transmission lines using coupled microstrip lines. This structure exploits the advantages of the microstrip lines, while increases the coupling by a floating conductor at the ground plane. The performance of this composite right/left-handed line is demonstrated by both simulated and measured results, and they show good agreement. The designed line has broad bandwidth with low losses and small size. A novel dominant mode leaky wave antenna design, using the previous structure, is presented with backward to forward scanning capability.

LEAKY WAVE ANTENNA REALIZATION BY COMPOSITE RIGHT/LEFT-HANDED TRANSMISSION LINE

2009-08-28

PIER Letters

Vol. 11, 31-38, 2009

doi:10.2528/PIERL09070901

download: 221

A Planar Eye Shape Antenna for Ultra-Wide Band Applications

Behzad Ahmadi

In this paper a new planar monopole antenna is presented. The performance parameters like return loss of the single antenna as well as transmission function, group delay, and the fidelity factor of a two-antenna system are calculated. The radiator is eye-shaped, and it can be used in dipole or monopole configurations. Good ultra wide band performance is achieved. Small size, simple design requirements and good performance are among the most advantageous features of this new of planar antennas.

A PLANAR EYE SHAPE ANTENNA FOR ULTRA-WIDE BAND APPLICATIONS

2009-08-28

PIER Letters

Vol. 11, 21-30, 2009

doi:10.2528/PIERL09072705

download: 334

A 16-31 GHz Miniature Quadruple Subharmonic Monolithic Mixer with Lumped Diplexer

Chih-Ming Lin , Jui-Ting Chang , Chun-Chi Su , Shih-Han Hung and Yeong-Her Wang

A novel 16-31 GHz quadruple subharmonic monolithic passive mixer with a chip dimension of 0.82×0.7 mm² is designed and fabricated using the 0.15 μm GaAs pHEMT process. The novel configuration of the quadruple subharmonic mixer consists of a lumped frequency diplexer and a low-pass filter utilizing a pair of anti-parallel Schottky barrier diode to achieve quadruple subharmonic mixing mechanism. The lumped frequency diplexer formed with a low-pass network and a high-pass network is used to reduce the chip dimension while operating at low frequency band and to improve the isolation between the RF and LO ports with a broadband operation. The low-pass filter supports an IF frequency range from DC to 2.5 GHz. From the measured results, the mixer exhibits a 12.5-16.5 dB conversion loss, a LO-to-RF isolation better than 15 dB, a 50-59 dB high 4LO-to-RF isolation over 16-31 GHz RF bandwidth, and an input 1 dB compression power of 2 dBm.

A 16-31 GHz MINIATURE QUADRUPLE SUBHARMONIC MONOLITHIC MIXER WITH LUMPED DIPLEXER

2009-08-28

PIER Letters

Vol. 11, 11-19, 2009

doi:10.2528/PIERL09072108

download: 242

Harmonic Suppression Characteristic of a CPW-Fed Circular Slot Antenna Using Single Slot on a Ground Conductor

Junho Yeo and Dongho Kim

A CPW-fed circular slot antenna with a slot on a ground conductor is presented for harmonic suppression. The antenna has a multi-band rejection characteristic where the second and higher rejection bands are integer-multiple of the first band, and this is generated by inserting single slot on a ground conductor of the antenna. Good agreement between the simulated and measured results is reported and the integer-multiple notch bands can be adjustable by changing the length of the slot on the ground plane.

HARMONIC SUPPRESSION CHARACTERISTIC OF A CPW-FED CIRCULAR SLOT ANTENNA USING SINGLE SLOT ON A GROUND CONDUCTOR

2009-08-28

PIER Letters

Vol. 11, 1-9, 2009

doi:10.2528/PIERL09080602

download: 226

Spoke Top Antenna for Transient Radiation

Julie A. LaComb

When an antenna transmits a short pulse of energy such as used for ultra-wide band applications, the pulse gets distorted upon transmission. To examine the properties of pulse transmission it is helpful to analyze the system in the time domain versus the frequency domain. Presented is a spoke top antenna for transient radiation. The spokes reduce the reflection from the open end of the antenna significantly reducing the trailing pulses commonly seen in the time domain. Comparisons are made with a dipole antenna. Both analytical, modeled and experimental results are presented.
