Abstract

This paper presents a novel, thin, circularly polarized microstrip antenna optimized for radar applications, designed to operate within the 7.5-7.7 GHz frequency band. The antenna is compact, with overall dimensions of 1.97λ x 1.08λ x 0.0025λ (where λ is wavelength calculated at 7.5 GHz) printed on a flexible polyimide substrate, offering advantages in terms of mechanical flexibility and integration into conformal systems. Circular polarization is achieved with an axial ratio of less than 3 dB across the operating bandwidth, while a peak gain of 6.25 dBi ensures adequate signal strength for radar detection and communication. Performance improvements are realized by introducing inverted C-shaped slots in the radiating element, effectively manipulating the surface current distribution and enhancing polarization purity and radiation efficiency. A prototype of the antenna was fabricated and tested, with experimental results closely matching simulation data, confirming the reliability of the design methodology. The results demonstrate that the proposed antenna is highly suitable for compact radar systems, offering an optimal balance among size, performance, and fabrication simplicity.

1. Barik, Rusan Kumar and Slawomir Koziel, "Ultracompact SIRC-based self-triplexing antenna with high isolation," Electronics, Vol. 12, No. 9, 2112, 2023.

2. Chung, Ming-An and Chih-Wei Yang, "Miniaturized broadband-multiband planar monopole antenna in autonomous vehicles communication system device," Electronics, Vol. 10, No. 21, 2715, 2021.

3. Lee, Won Jun, Won-Sang Yoon, Dal Ahn, and Sang-Min Han, "Compact design method for planar antennas with defected ground structures," Electronics, Vol. 12, No. 10, 2226, 2023.

4. Sufyan, Ali, Khan Bahadar Khan, Osama A. Khashan, Talha Mir, and Usama Mir, "From 5G to beyond 5G: A comprehensive survey of wireless network evolution, challenges, and promising technologies," Electronics, Vol. 12, No. 10, 2200, 2023.

5. Kishore, N. and A. Senapati, "5G smart antenna for IoT application: A review," International Journal of Communication Systems, Vol. 35, No. 13, e5241, 2022.
doi:10.1002/dac.5241

6. Tubbal, F., L. Matekovits, and R. Raad, "Antenna designs for 5G/IoT and space applications," Electronics, Vol. 11, No. 16, 2484, 2022.
doi:10.3390/electronics11162484

7. Pearson, James and Robert Romanofsky, "Thin film antenna development and optimization," 47th AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics, and Materials Conference 14th AIAA/ASME/AHS Adaptive Structures Conference 7th, 2229, Newport, Rhode Island, USA, 2006.

8. De Cos Gómez, M. E., H. Fernández Álvarez, C. García González, B. Puerto Valcarce, J. Olenick, and F. Las-Heras, "Ultra-thin compact flexible antenna for IoT applications," 2019 13th European Conference on Antennas and Propagation (EuCAP), 1-4, Krakow, Poland, Mar. 2019.

9. Genovesi, Simone, Filippo Costa, Filippo Fanciulli, and Agostino Monorchio, "Wearable inkjet-printed wideband antenna by using miniaturized AMC for sub-GHz applications," IEEE Antennas and Wireless Propagation Letters, Vol. 15, 1927-1930, 2016.

10. Asghar, Muhammad, Sergey Lupin, Sultan Shoaib, and Peter Excell, "Design and analysis of compact antenna for 5G communication devices," 2020 IEEE Conference of Russian Young Researchers in Electrical and Electronic Engineering (EIConRus), 2236-2239, St. Petersburg and Moscow, Russia, Jan. 2020.

11. Kishore, Nawal and Anupama Senapati, "5G smart antenna for IoT application: A review," International Journal of Communication Systems, Vol. 35, No. 13, e5241, 2022.

12. Ali, Tanweer, A. W. Mohammad Saadh, Rajashekhar C. Biradar, Jaume Anguera, and Aurora Andújar, "A miniaturized metamaterial slot antenna for wireless applications," AEU --- International Journal of Electronics and Communications, Vol. 82, 368-382, 2017.
doi:10.1016/j.aeue.2017.10.005

13. Saeidi, Tale, Idris Ismail, Wong Peng Wen, Adam R. H. Alhawari, and Ahmad Mohammadi, "Ultra-wideband antennas for wireless communication applications," International Journal of Antennas and Propagation, Vol. 2019, No. 1, 7918765, 2019.

14. Desai, Arpan, Trushit Upadhyaya, and Riki Patel, "Compact wideband transparent antenna for 5G communication systems," Microwave and Optical Technology Letters, Vol. 61, No. 3, 781-786, 2019.

Dr. Palaniselvan Sundaravadivel

Dr. Sathiyapriya Thangavel

Dr. Gold Beulah Patturose Jegajothi

Dr. Rethinasamy Meenakshi

Dr. Dhanushkodi Siva Sundhara Raja

Dr. Rajesh Kumar Dhandapani
