2024-07-22
Miniaturized Dual-Polarized, High-Gain, and Wideband Dielectric Resonator Antenna for Low Band Massive MIMO Applications
By
Ahmed El Yousfi,

    Mr. Ahmed El Yousfi

    Signal Theory and Communication Department

    The University Carlos III of Madrid

    Spain

    Homepage

Kerlos Atia Abdalmalak,

    Mr. Kerlos Atia Abdalmalak

    Signal Theory and Communications

    Universidad Carlos III de Madrid

    Spain

    Homepage

Abdenasser Lamkaddem,

    Mr. Abdenasser Lamkaddem

    Signal Theory and Communication Department

    University Carlos III of Madrid

    Spain

    Homepage

Alejandro Murrillo Barrera,

    Dr. Alejandro Murrillo Barrera

    Huawei Technologies Duesseldorf GmbH

    Germany

    Homepage

Bruno Biscontini,

    Dr. Bruno Biscontini

    Huawei Technologies Duesseldorf GmbH

    Germany

    Homepage

Daniel Segovia-Vargas

    Prof. Daniel Segovia-Vargas

    Signal and Communications

    Universidad Carlos III de Madrid

    Spain

    Homepage

Progress In Electromagnetics Research, Vol. 179, 101-111, 2024
doi:10.2528/PIER24021303
Abstract
A new dual-polarized compact crossed-notched dielectric resonator antenna (DRA) array with high-gain and wideband performance is proposed for low-band massive multiple-input multiple-output (MIMO) applications at the 700 MHz band of 5G new radio (5G NR) technology. The DRA element consists of three dielectric layers with relatively high relative permittivity constants (εr1 = 15 for the bottom and top layers and εr2 = 23 for the middle one) for a compact antenna. Characteristic mode analysis (CMA) of a rectangular DRA reveals that two pairs of degenerate modes, namely M2/M3 and M4/M5, resonating at 0.4 and 0.6 GHz respectively can be used to achieve dual polarizations with a proper feeding strategy. By jointly reshaping the conventional DRA along with adding a notch into the middle dielectric layer the two pairs of degenerate modes are merged to produce a broad bandwidth with a compact size of 0.2λmax × 0.2λmax (λmax being the wavelength at low-frequency point). The measured results show an impedance bandwidth of 13.15% (710 MHz-810 MHz) and an isolation of less than -17 dB. Furthermore, the antenna exhibits a good radiation pattern over the working band with a high gain of 7 dB. Finally, the proposed element is tested in a massive MIMO system of 3×4. The results exhibit a wideband of 17.7% and high isolation of more than 12 dB along with a stable gain of 5 dBi within the operating band.
Citation
Ahmed El Yousfi, Kerlos Atia Abdalmalak, Abdenasser Lamkaddem, Alejandro Murrillo Barrera, Bruno Biscontini, and Daniel Segovia-Vargas, "Miniaturized Dual-Polarized, High-Gain, and Wideband Dielectric Resonator Antenna for Low Band Massive MIMO Applications," Progress In Electromagnetics Research, Vol. 179, 101-111, 2024.
doi:10.2528/PIER24021303
